86×86 Or Custom
CS Or Custom
Overview
Essential details
Place of Origin | Zhejiang, China | Brand Name | Custom |
Model Number | Custom | Protection Level | IP66 |
Type | Junction Box, precast concrete production | External Size | Custom |
Product Name | Junction Socket Box | Size | 86# |
Material | PVC | Sample | Support |
ODM/OEM | Support | Color | Withe |
Application | Industrial | Packing | Carton And Pallet |
After Sale Service | Online Technical Support | ||
Product Description
Specification
Product Name | Junction Socket Box |
Size | 86×86 Or Custom |
Material | PVC Or Steel |
Application | Industrial Magnet For Architecture Industry |
Steps for Wiring and Installing a Junction Box
First, turn off the power for the circuit you’ll be using. (If there’s a light on that circuit, turn it on before you flip the circuit breaker, and if it turns off, you can be reasonably sure that the circuit is disconnected. But don’t do anything yet!)
Use the voltmeter or non-contact circuit tester to check whether the conductors are actually disconnected. When you’re sure that there’s no current, proceed to the next step.
If you’re installing a Switch Box, use screws or nails to attach the box to a stud, positioned so that the face of the box is flush with the drywall. Exterior boxes should be attached with screws; the back of the box should have small holes for that purpose. If you have a metal box, use a screwdriver as a lever to remove the knockouts (the precut metal discs on either side of the Switch Socket Box). You’ll also need to install cable clamps in the metal box. These thread into the box from the outside. Plastic boxes have integral clamps.
Bring the cables into the box through the clamps. Make a mark on the cable about ½ inch beyond the clamp, withdraw the cable, measure and cut the conductors about 6 inches beyond the mark, then strip the cable’s plastic or metal sheathing back to the mark. Bring the cable back into the box. If it’s a metal box, tighten the cable clamps onto the sheathing; plastic box clamps are self-tightening.
Wire strippers have gauged cutters for various sizes of wire. Choose the proper gauge for the wire you’re using, then test the gauge by placing the end of one conductor into the stripper, squeezing down to score, and pull off the insulation. Examine the conductor. If you’ve cut or damaged some of the wire, use the next larger gauge. Now use the wire strippers to remove ¾ inch of the insulation from the end of each conductor.
When all the conductors have been stripped, join the bare copper or green insulated ground wires first. Use pliers or the gripping end of the wire strippers to twist the ground wires together, then twist a wire nut onto the wires to keep them together. Note: If you’re working with a metal box, you’ll need to add a pigtail (a separate 4- to 6-inch length of ground wire) to the other grounds and connect it to the green ground screw located inside the box. Wrap the pigtail clockwise around the screw and tighten the screw. Note: Be sure to use the correct size wire nut: if the nut is too small, the wires won’t fit, and if it’s too big, the wires could loosen and fall out. Wire nuts are color-coded for AWG and capacity, both of which are also listed on their packaging. For instance, an orange wire nut is rated for use with a minimum of two 18-AWG wires to a maximum of three 16-AWG wires.
Now connect the neutral (white) wires, then the hot (black) wires, following the procedures outlined in Step 6. Give the wire nuts a tug to make sure they’re on tight and there are no loose wires. Carefully and neatly fold the joined wires back into the box. Place the cover onto the box front and tighten the screws. Now you can turn the power back on and check to see that your connections are working.
More Products
Insert Magnet
Applications
Company Profile
Ningbo Custom Hardware Technology Co., Ltd providing comprehensive one-stop shop Precast concrete products solutions. It is one of the longest and largest manufacturers of Precast concrete magnetic fixing products in mainland China. It's main in Precast Concrete Shuttering Magnets,Grouted Rebar Sleeves,Loop Clamp, Lifting Sockets Insert ,Anchor Bolt,magnetic chamfer and precast concrete embedded parts magnetic fixture.We have a mature R & D team and advanced full-scale production equipment. The factoy is more than 6000square. We're a firm-united team of talented and experienced engineers, machinists and technical consultants, We are engaging in providing full solutions in magnetic fixing for precast concrete industry to improve the production efficiency and reduce the manual operation for precast concrete factories all around the world. Ningbo Custom Hardware has the most extensive range of network in China and our products have been exported about 30 countries, such as USA, South America, Europe, Australia , South Africa, Middle East and Southeast Asia, etc. Our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction. Higher quality and best services are the beliefs where the company stand for and the reasons of the stable and ambitious growth.Welcome to contact us for more details! We are sure that we could give you the high quality and satisfied service.
Supply Ability
Supply Ability 2000000 Piece/Pieces per Month
Packaging & delivery
Packaging Details: Carton
Port: NINGBO,SHANGHAI,SHENZHEN
Lead time:
Quantity(pieces) | 1 - 10000 | 10001 - 1000000 | >1000000 |
Lead time (days) | 7 | 20 | To be negotiated |
Picture Example:
